D 914 L3 (Agri)

Engine for agricultural machinery.
Air-cooled 3-cylinder naturally aspirated in-line-engine.
6-cylinder turbocharged, charge air cooled
Displacement: 1.1 liter/cylinder
Modular system with single cylinder units
Advanced injection and combustion system
Worldwide approved: more than 4.5 million engines in use
100 percent power take-off on the flywheel side and on the face end
Possibility of power take-off for hydraulic pumps and compressor
Only few maintenance points
Compact power-pack with low weight

Technical data
Emission norms EU IIIA, EU II, US T2, US T3
Number of cylinders 3
Bore 102 mm
Stroke 132 mm
Displacement 3.2 l
Maximum nominal speed 2300 rpm
Power output 43 kW
at speeds 2300 rpm
Max. torque 204 Nm
at speeds 1500 rpm
Min. idling speed 700 rpm
Specific fuel consumption 225 g/kWh
Length 708 mm
Width 666 mm
Height 796 mm
Weight 277 kg
