BF 6 M 1015 M

Modern water-cooled four stroke 6-cylinder V-engine.
Water-cooled turbocharger and exhaust manifolds.
PTOs gear driven.
Modern injection system with mechanical governor.
Electronical governor for gen set application.
Charge-air-cooler by engine cooling liquid.
Innovative DEUTZ Multi-Parallel-Cooling System.
Compact design.

Technical data
Number of cylinders	6
Bore	132 mm5.2 in
Stroke	145 mm5.7 in
Displacement	11.9 l726 cu in
Propulsion engines LG A	214 kW287 hp
Propulsion engines LG B	240 kW322 hp
Specific fuel consumption	213 g/kWh0.35 lb/hph
Length	1379 mm54.3 in
Width	1316 mm51.8 in
Height	1159 mm45.6 in
Weight	1080 kg2381 lb
